With perfection for the automated alignment of your optical components
With our production systems you have a fully automated solution at hand that will raise your production to a completely new level of quality.
With high-precision micromanipulators and measuring technology, the component quality increases and your reject rate is minimized. Active alignment processes are not uncritical for the performance of your optical products such as camera and LiDAR modules, MEMS components, LEDs and lasers. Talk to our experts about your specific requirements
Positioning accuracies less than 10 nm. Manipulation of highly sensitive, optical components in six degrees of freedom are the basis for active alignment.
Placer 3D Hexapod Rotations
Modular alignment unit for your automated process
This placer was specially developed for active alignment tasks. In addition to a travel distance of 150 mm in Z direction, it has a +/- 50 ° range around the movement axis. A hexapod with six axes, using integrated movements in all 6 degrees of freedom guarantees fine positioning and alignment of optical components. Furthermore vacuum, compressed air or piezo based (micro gripper from SmarAct) tools can be attached. An adjustable inspection camera views into the machining area. In addition, the range of functions is expandable by contact pins, UV lamps, etc..
Talk to our experts about your specific requirements.
